18 Sound 15NLW4500-4 15-inch Extended Low Frequency Loudspeaker 1500 Watts Rms 3000 Watts Peak 4-Ohm Motorcycle Car Pro Audio Component Sound Speaker
- GENERAL Brand : 18 SOUND Model Number : 15NLW4500-4 15NLW4500 UPC : 8054752261587 DESIGN Magnet Material : Neo Recommended Enclosure : 50.0 dm3 1.77 ft3 Recommended Tuning : 45 Hz
- FEATURES 115mm 4.5in Interleaved Sandwich Voice coil ISV Weather protected cone and plates Great heat dissipation capability Ultra linear suspension system Neo motor for high power and very efficient thermal exchange Single demodulating ring SDR for distortion reduction and maximum SPL
- SPECIFICATIONS Nominal Impedance : 4 Minimum Impedance : 3.7 Nominal Power Handling : 1500 W Continuous Power Handling : 3000 W Sensitivity : 96.6 dB Frequency Range : 40 – 1000 Hz Voice Coil Diameter : 115 mm 4.53 in
- PARAMETERS Resonance Frequency : 35 Hz Re : 3.0 Qes : 0.21 Qms : 6.38 Qts : 0.2 Vas : 126.0 dm3 4.45 ft Sd : 881.0 cm2 136.56 in : 2.13 % Xmax : 14.5 mm Xvar : 12.0 mm Mms : 198.0 g Bl : 24.4 Txm Le : 1.1 mH EBP : 166 Hz
- MOUNTING AND SHIPPING INFO Overall Diameter : 393 mm 15.47 in Bolt Circle Diameter : 371 mm 14.61 in Baffle Cutout Diameter : 356.0 mm 14.02 in Depth : 199 mm 7.83 in Flange and Gasket Thickness : 15 mm 0.61 in Net Weight : 11.4 kg 25.13 lb Shipping Weight : 12.6 kg 27.78 lb
