AIMS Power 5000 Watt 48 Volt Modified Sine Inverter

$90.49

Description

AIMS compact 5000 Watt modified sine wave power inverter 48 VDC. This inverter is packed with power but still small enough to fit in small spaces. The 48 VDC is more efficient and generates less heat. This inverter is capable of providing up to 41.6 AC amps, which is perfect for larger pumps, tools, compressors and refrigerators/freezers. Includes volt and amp meter, optional remote, AC direct connect terminal block and 4 AC receptacles.

  • Features:

    • 5000 Watt max continuous power
    • 10,000 Watt surge (not recommended for start up applications)
    • 48 Volt DC Power Inverter
    • Modified sine wave
    • Volt meter on front panel to monitor your battery voltage
    • Amp meter on front panel to monitor your current use (rate at which battery is drained)
    • AC direct Connect Terminal
    • Over temperature LED indicator
    • Over load LED indicator
    • Quadruple ac receptacle that can be used with any separate spliter to provide even more outlets
    • On/off switch
    • Over temperature protection
    • Over load protection single cooling fan operation thermally controlled internally fuse protected ac output short circuit protection
    • Auto reset on most fault conditions
    • Aluminum case for optimal cooling
    • Pre-wired for remote on/off switch
    • Pre-slotted mounting plate
    • Instruction manual
    • Free 1 year tech support
    • 1 Year warranty parts and labor

  • Specifications: 5000 WATT MODIFIED SINE INVERTER

    • Continuous output power: 5000 Watt
    • Surge power capability (peak power): 10,000 Watt
    • Dc input / operating voltage: 39 to 64 V
    • Output voltage: 120 VAC +/- 10%
    • Output wave form: modified sine wave with phase correction
    • Output frequency: 60 Hz +/- 1 Hz
    • Battery low voltage alarm: 40 +/- 0.5 V
    • Battery low voltage shutdown: 38 +/- 0.5 V
    • No load current: < 0.2 amps
    • Full load efficiency: 90%
    • 1/3 load efficiency: 95%
    • No load minimum operating temperature: -15 degrees Celsius
    • Full load maximum operating temperature: 55 +/- 5 degrees Celsius (automatic shutdown)
    • AC Output Socket Type: quadruple Type 2 -3 prong
    • AC Output Socket Type: quadruple Type 2 -3 prong
    • High input voltage protection: 64 V
    • Low input voltage shutdown: 38 V845
    • Internal fuse protection
    • UL maximum recommended per outlet 1500 Watt
    • Battery terminals 1/8″
