AIMS Power PICOGLF40W12V120V 4000 WATT PURE SINE INVERTER CHARGER 12Vdc TO 120Vac OUTPUT

$87.27

Description

This is the AIMS 4000 Watt low frequency pure sine wave inverter charger. It is an inverter, charger and transfer in one unit! This inverter boasts a 12,000 watt surge capacity for 20 seconds and will deliver that sheer amount of power on demand. This is the 12 volt dc to 120 volt ac version with single bolt type dc terminals that will accept 4/0 (0000 AWG) cable.

This 4000 watt inverter charger has a solid build, coming in at just over 80lbs shipped, the huge copper wound transformers inside can discharge reliable true sine wave power at a moments notice. This inverter is Marine, Military and Industrial Grade and can take on many heavy tasks such as running 110 volt compressors, window air conditioners, large televisions, microwaves, computers, servers and many more items that you might want to run.

The AC terminal block allows you to wire directly into a 110v-120v distribution box/breaker box to go into multiple outlets. Making this perfect for RV’s, yachts, fishing boats, ambulances, fire trucks, utility vehicles and trucks, tactical response vehicles, military vehicles, tour buses and more.

  • 4000 WATT PURE SINE INVERTER CHARGER 12Vdc TO 120Vac OUTPUT
    Output Specifications:
    • Continuous output power: 4000 Watt
    • Surge rating: 12000 Watt (20 seconds)
    • Output waveform: pure sine/same as input (bypass mode)
    • Nominal efficiency: >88% (peak)
    • Line mode efficiency: >95%
    • Output frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
    • Typical transfer time: 10ms (max)
    • THD: < 10% DC

    Input Specifications:

    • Nominal input voltage: 12.0 VDC
    • Minimum start voltage: 10.0 VDC
    • Low battery alarm: 10.5Vdc +/= .5 VDC
    • Low battery trip: 10.0Vdc-10.5 VDC
    • High voltage shutdown: 16.0 VDC
    • Low battery voltage restart: 13.3 VDC
    • Idle consumption: <3.47 amps DC
    • Power saver mode idle consumption: <0.53 amps DC

  • Charger Specifications:

    • Output voltage: Depends on battery type
    • Charger rate: 115 A
    • Over charge protection shutdown 15.7 V
    • Selectable charge setting based on battery type
    • Adjustable charge current off – 20%-100%
    • Four stage smart charger charges gel, lead acid, AGM and lithium LiFePO4 batteries
  • Transfer Switch Specifications:
    • 40 amp automatic transfer switch
    • 10 ms (max)
  • This inverter has a 115 amp four stage smart battery charger, providing rapid charge to any type of 12 volt battery configuration you may have. The built in transfer switch boasts a lightning fast 10ms transfer time..
